KL 203

Features

• High-efficient manufacture system, planned and realized for particular customer application
• High seam quality and stitch reliability
• Max. process reliability, also when sewing highest speed
• Standard sewing head, double lockstitch or double chainstitch (1- or 2-needle )
• Free programmable tacking of seam beginning and seam end / stitch densification
• Stationary/movable sewing head
• Exchangeable folding apparatus and material guidance
• The machines are planned individually with the customers and implemented in their production



Options

• Free programmable height of the presser foot, pneumatic/electromotive, as well as second thread tension adjustable during the sewing process
• Integration of an automatic top / bottom tape feeder for seam reinforcement with tape cutter and tape advance
• Various tape monitoring units and thread cutters depending on customer demands
• Integration of material fixation devices

Specifications

Seam length: up to 10.000 mm
Max. stitch length: depending on sewing head
Max. sewing speed: depending on sewing head
